Instrument Overview

The Thermo Scientific NanoDrop One is a next-generation microvolume spectrophotometer developed by Thermo Fisher Scientific, integrating advanced optical systems with intelligent operation capabilities. This instrument enables rapid and accurate measurement of concentration and purity for various samples including nucleic acids, proteins, and cell culture media, making it suitable for life science research, drug development, and quality control applications.

Core Technical Features

Microvolume Detection: Requires only 0.5-2 μL of sample for measurement using surface tension technology, eliminating the need for consumable cuvettes. Detection range covers 0.2-27,500 ng/μL (dsDNA) with optional 10 mm long path length mode.

Full Spectrum Analysis: Utilizes high-energy xenon flash lamp and CCD array detector with wavelength range of 190-850 nm. Completes full spectrum scanning within 5 seconds while automatically saving raw spectral data.

Temperature Control: Features unique cuvette temperature control module supporting precise temperature regulation from 4-65°C with magnetic stirring capability for kinetic studies.

Application Areas

1. Nucleic Acid Analysis: Precise quantification of DNA/RNA concentration and purity, supporting small molecules including ssDNA and microRNA

2. Protein Quantification: Direct UV absorption method for protein concentration measurement, supporting various dye-based methods including BCA and Bradford

3. Cell Research: Bacterial/yeast cell density measurement, mammalian cell viability detection

Intelligent System

• 8-inch capacitive touchscreen with gesture control support

• Pre-loaded with 30+ detection methods for one-click operation

• Automatic standard curve generation with multiple format data export

• Wi-Fi and Ethernet connectivity for cloud data storage

Technical Advantages

High Precision Measurement: Dual-beam optical design with CV <1%

Broad Compatibility: Supports various sample types with automatic contaminant detection

User-Friendly Design: Automatic measurement arm positioning and self-cleaning optical surfaces

Optional Components: Cuvette module and autosampler availability

This instrument has become an indispensable analytical tool in laboratories due to its exceptional performance, intelligent operation, and reliable results, providing researchers with fast and accurate sample quality assessment solutions.

(Note: Specific technical parameters may vary depending on configuration. Please refer to actual product specifications.)
